| Transformer-Parameters | ||||||
| Capacity | 700KVA-1500KVA | Coil Material | Copper or Aluminum | |||
| AC Input | Phase | 3φ4W | Steel sheet material | WISCO Silicon Steel | ||
| Voltage | AC 380V(Optional, e.g.:110V, 210V, 400V, 415V, 460V, 600V and More) | Power Factor | 0.8 to 1 Optional | |||
| Frequency | 50Hz/60Hz | Efficiency | 98% | |||
| AC Output | Phase | 3φ4W | Withstand Voltage | 3000V/1min | ||
| Voltage | AC 220V 200V(Optional,e.g.: 110V, 210V, 400V, 415V, 460V, 600V and More) | Temperature Rise | Winding temperature rise<70K | |||
| Frequency | 50Hz/60Hz | Insulation Grade | H Grade | |||
| Electric Current | A | Impedance Voltage Drop | ≤6% | |||
| Display | Input Voltage | Customizable | Insulation Resistance | DC500C≥100MΩ | ||
| Output Voltage | Connecting Groups | Yyn0/Dyn11/Ynd11 | ||||
| Work Information | Waveform Distortion(THD) | No Distortion | ||||
| Weight（kg） | kg | No-load loss | ≤2% | |||
| Volume(mm) | L*W*H | Protection grade | Customizable | |||
| Operation Temperature | -20℃～+45℃ | Noise | ≤55db | |||
| Relative Humidity | ≤90% | Chassis Material | Steel plate shell, Surface electrostatic spraying |
|||
| Altitude | Optional | Cooling Mode | Fan cooling Natural cooling |
|||
| Warranty | 2 Years | After-sale service | Within 1 day | |||
|
|
|
 |
 |
| Question 1.: | Are you a manufacturer? |
| Reply: Absolutely.Our factory is a true industrial power supply manufacturer.
Welcome to verify our factory any time! |
|
| Question 2.: | How is the quality of your product? |
| Reply: Our factory uses internationally renowned brands of non oriented silicon steel or oriented silicon steel to achieve low iron loss and high magnetic induction. | |
| Question 3.: | What is the delivery time? |
|
Reply:The standard delivery time is 7-10 working days. it is more than 15 working days. |
|
| Question 4.: | Can we customize the logo? |
| Reply:certainly.Our own factory supports ODM/OEM orders. | |
| Question 5.: | What is the minimum order quantity? |
| Reply:Minimum order quantity for standard products is 1 unit. | |
| Question 6.: | Why choose SINCRON products? |
|
Replay: A. Material: SINCRON uses international first-line brand raw materials and guarantees 100% brand new, allowing you to clearly understand where your cost consumption is. |
|
